Dakota Digital VHX-1018-C-R Universal Recessed 4.4″ x 11.4″ Rounded Rectangle Analog Gauge System Carbon Fiber Style Red Backlighting

Checking in at 11.4″ wide, 4.4″ tall and 2″ deep, VHX-1018 offers great visibility and features in a compact package. The graceful instrument housing in flawless chrome plating perfectly complements the backlit VHX system making this a classy option that fits nearly any vehicle.

*Includes chrome bezel

Fully lit needles, backlit faces, and highly visible LCD message centers are Among the things that you’ll see which set the VHX Series except for the day past’s traditional approach to instrumentation. Among the features which you don’t most often see are the micro-controlled precision stepper motors, solid state sensors for unparalleled accuracy, and user-customizable display feedback, all supported by an unrivaled limited lifetime warranty which has turn into the standard for Dakota Digital instrumentation systems. Completely engineered and manufactured at Dakota Digital’s facility in Sioux Falls, South Dakota, the VHX Series has completely revolutionized the instrumentation industry!

Analog Gauges:

Speedometer – 0-160 MPH
Tachometer – 0-8000 RPM
Oil Pressure – 0-80 psi
Water Temperature – 100-260ºF
Fuel Level – E, 1/4, 1/2, 3/4, F
Voltmeter – 9-17 VDC

Digital Message Centers:

Standard Displays:

-Odometer (One time user settable, Million Mile)
-Dual (A/B) Commute Meter (0- 9,999.9)
-Clock (12 hour)

Performance Meters:

-0-60 MPH Timer (0- 100 kmh)
-1/4 mile time
-1/4 mile end speed (trap speed)
-High speed recall
-High RPM recall

Built-In Indicators:

-Turn Signals (Left/ Right)
-High Beam
-Check Engine
-Parking Brake
-Cruise Regulate (On/ On & Engaged when vehicle is equipped)
-Gear Position (Optional GSS-3000 sensor required, sold one by one)
-4 x 4 and Wait to Start (When vehicle is equipped)

Included Senders:

Water Temperature, Oil Pressure and Speed Sender (Replaces GM style speedometer cables with a 10ft harness)

Included Displays: Speedometer, Tachometer, Oil Pressure, Water Temp, Voltmeter, Fuel Level.
Also shown in digital message center: Odometer, Commute Odometer, Resettable Service Odometer, Clock, Hour Meter, 0-60 MPH Timer…
Quite a lot of Indicators can be displayed: Turn Signals, High Beam, Check Engine, Parking Brake, Cruise Regulate…
Necessary sensors included for oil pressure (1/8” NPT), Water Temp (1/8″ with bushings for 1/4″, 3/8″, 1/2” NPT as well 12mm and 16mm for GM & LS applications) and speedometer pulse generator.
VHX-1018-C-R (carbon fiber style/red backlighting) – The new Universal VHX-1018 Rounded Rectangle gauge cluster measures 11.4″ x 4.4″
